THÔNG SỐ KĨ THUẬT:

Transmitter variant	Coriolis transmitter FCT030
Mounting style, Transmitter Housing & Material	Remote mounted transmitter Aluminium IP67 / NEMA 4X Terminal box for sensor cable
Ex approvals	Standard, no Ex approval
Cable glands	Nylon cable glands metric thread, limited to -20C/-4F
Power supply	Power supply: 24VAC/DC - 230VAC 50/60 Hz
Enclosure protection rating	IP67 / NEMA 4X
Local user interface	Graphical local user interface, 240x160 pixels, Lid window in Panzer glass
Software functions & CT approvals	Standard software (Transmitter)
I/O Configuration Ch 1	Current Output 4-20 mA, HART, active/passive Non-Ex
fix value	.
I/O Configuration Ch2 (O), Ch3 (I/O) & Ch4 (I/O)	No optional inputs and outputs

Danh mục phụ tùng :

A5E03549344	Lid aluminum, glass window, seal FVMQ
A5E03549396	Loose spare parts, industrial enclosure
A5E03549413	FC030 Power Supply chassis
A5E03549429	Lid aluminum, no window, seal FVMQ
A5E03915258	SensorFlash (4 GB micro SD card)
A5E37705139	Display unit, industrial enclosure
A5E38013040	Transmitter module, non-Ex, HART
A5E38264471	Power supply module, industr. enclosure
A5E38288507	4 GB micro SD card, -40°C ... 85°C
A5E39844362	Display unit, industr. encl., brandless
A5E41526318	Sparepart compact frontend
